UFI Ultra-D Submicron Filter Series
UFI ULTRA-D submicron filter series are manufactured using a proprietary, electro adhesion and ion exchange media. This unique material makes it possible for a non woven media to perform comparable to ultra-membrane filtration. This avoids the inherent high clean pressure drop and low flow rates associated with membrane filtration. ULTRA-D filters are offered in two configurations with four media options.
5283 – WHITE (BLUE CAP)
Offers high flow rates with submicron filtration of 0.2 microns. Offers enhanced removal of submicron particles to include organic and inorganic compounds, colloids, and biologic materials to include virus, bacteria, organic acids cell debris, and endotoxins.
5288 – WHITE W/SILVER (RED CAP)
Offers submicron high flow performance with Agion silver additive. Agion prevents colonization of organisms captured on the filter surface and is not absorbed into human tissue.
5284 – WHITE W/CARBON (BLACK CAP)
Offers all the advantages of the 5283 media with added benefit of PAC carbon to address chlorine, taste, odour, humic acid and other water-soluble components common to portable water sources.
5289 – WHITE W CARBON AND SIILVER (GREEN CAP)
Combines the advantages of 5284 and 5288 media into a single cartridge.
CONTROLLED INDEPENDENT LABORATORY TESTING DOCUMENTS THE REDUCTION OF HEAVY METALS, CHEMICALS AND ORGANIC/INORGANIC COMPOUNDS AS FOLLOW –
Lead Reduction – 95%
Ferrous Iron – 80%
Arsenic V – 95%
Cadmium – 95%
Chromium – 85%
Selenium – 75%
Mercury – 60%
Viruses – 99.99%
Bacteria (e coli, legionella, pseudomonas, etc.) – 99.99%
Cysts (giardia, cryptosporidium, etc.) – 99.95%
Chlorine (5284 PAC)
Bromine (5284 PAC)
Iodine (5284 PAC)
VOCs (volatile organic compounds)
PCB and BPA
Residual Pharmaceuticals
Biofouling Precursors – Organic Acids, Proteins and Polysaccharides
Ultra D cartridges are offered in an ECO configuration with fewer pleats and a life extending five-micron outer protective wrap. The wrap supports a mildlife external rinse capability not available with the standard configuration. ECO offers a cost effective alternative to the standard and ideally suited for single cartridge applications.
All Ultra D filter options are certified to NSF42 and 61 standards by IAPMO RT. They are available with 2.0” to 6.0” diameters and lengths of 4” to 40”.
NSF/ANSI 42/61 CERTIFIED
